Original Drawings:
N40 Profile
N40 Interior
N40 Port Interior
N40 Starboard Interior
Vessel Specifications:
| Designer: | PAE | |
| Manufacturer: | Pacific Seacraft (PSC) in California | |
| Build Year: | 2000 | |
| LOA: | 39′ 10″ | 12.14m | |
| Beam: | 14′ 5″ | 4.39m | |
| LWL: | 35′ 4″ | 10.78m | |
| Maximum Draft: | 5′ 2″ | 1.58m | |
| Displacement: | 50,000 lbs | 22,679.62 kg Dry Load (25 Tons) | |
| Ballast: | 4,000 lbs | 1,814.37 kg | |
| Headroom: | 6′ 4″ | 1.93m | |
| Fresh Water Tanks: | Fiberglass (220USG | 832.79L) | |
| Fuel Tanks: | Fiberglass (920USG | 3,482.58L) | |
| Holding Tanks: | Fiberglass (68USG | 257.41L) | |
| Engines | #1 | #2 |
| Engine Brand: | Lugger | Yanmar |
| Year Built: | 2000 | 2000 |
| Engine Model: | L668D | 3GM30 |
| Engine Type: | Inboard | Inboard |
| Engine/Fuel Type: | Diesel | Diesel |
| Drive Type: | Direct Drive | Direct Drive |
| Engine Power: | 105 HP | 27 HP |
| Cruising Speed: | 7 knots | 13 km/h | 3.5 knots | 6.5 km/h |
| Maximum Speed: | 8 knots | 15 km/h | 4.5 knots | 8 km/h |
M/V MIGRATOR 1
